Single Compression Medium Duty Cable Glands
 |
Technical Data:
| Material |
: |
Brass |
| Plating |
: |
Nickle Plated Standard,
(Chrome also available) |
| Entry Threads |
: |
BSC Standard
(Metric also available) |
| Sealing Rubber Ring |
: |
Natural |
Application:
Used in normal climatic condition for armoured & unarmoured cables.
|
Suitable Cable
Overall Dia |
Size |
A
Nipple Entry |
D2
Dia. |
D3
Dia. |
D4
(A/F) |
D5
(A/F) |
L1
Length |
| From |
To |
mm |
Inches |
Inches |
Ø mm |
Ø mm |
mm |
mm |
mm |
| 6.0 |
9.0 |
10 |
3/8" |
5/8" |
12.0 |
12.5 |
18.0 |
20.5 |
7.0 |
| 9.0 |
12.0 |
12 |
1/2" |
5/8" |
12.5 |
15.5 |
20.5 |
23.5 |
7.0 |
| 12.0 |
14.0 |
16 |
5/8" |
3/4" |
15.0 |
16.0 |
20.5 |
23.5 |
7.0 * |
| 14.0 |
16.0 |
19 |
3/4" |
3/4" |
15.0 |
18.0 |
23.0 |
26.0 |
7.0 * |
| 16.0 |
18.0 |
22 |
7/8" |
3/4" |
15.0 |
20.5 |
25.0 |
29.0 |
7.0 * |
| 18.0 |
21.5 |
25 |
1" |
1" |
21.0 |
23.5 |
28.5 |
32.5 |
8.0 * |
| 21.5 |
26.0 |
28 |
1 1/8" |
1 1/8" |
24.5 |
27.5 |
33.0 |
38.0 |
8.5 * |
| 26.0 |
31.0 |
32 |
1 1/4" |
1 1/4" |
27.0 |
31.5 |
37.0 |
43.0 |
11.0 * |
| 31.0 |
34.0 |
35 |
1 3/8" |
1 3/8" |
29.5 |
35.5 |
42.0 |
48.0 |
11.0 * |
| 34.0 |
38.0 |
38 |
1 1/2" |
1 1/2" |
33.0 |
38.0 |
45.0 |
52.0 |
11.0 * |
| 38.0 |
42.0 |
45 |
1 3/4" |
1 3/4" |
38.5 |
44.5 |
52.0 |
60.0 |
11.0 * |
| 42.0 |
48.0 |
50 |
2" |
2" |
45.0 |
52.0 |
58.0 |
67.0 |
11.0 * |
| 48.0 |
54.0 |
57 |
2 1/4" |
2 1/4" |
51.0 |
57.5 |
65.0 |
75.0 |
13.0 |
| 54.0 |
60.0 |
63 |
2 1/2" |
2 1/2" |
57.0 |
63.0 |
70.0 |
81.0 |
13.5 |
| 60.0 |
66.0 |
70 |
2 3/4" |
2 3/4" |
63.0 |
69.0 |
77.0 |
89.0 |
13.5 |
| 66.0 |
72.0 |
75 |
3" |
3" |
69.0 |
75.0 |
83.0 |
96.0 |
13.5 |
| 72.0 |
78.0 |
82 |
3 1/4" |
3 1/4" |
76.0 |
81.5 |
90.5 |
104.0 |
14.0 |
| 78.0 |
84.0 |
88 |
3 1/2" |
3 1/2" |
77.0 |
84.0 |
96.0 |
110.0 |
15.0 |
| 84.0 |
92.0 |
100 |
4" |
4" |
90.5 |
99.0 |
110.0 |
126.0 |
16.0 |
* Gland body with long nipple length also available | Tolerance + 1mm |
|
